Force Layout Directed Graph using dot engine dagre-d3js library, data from JSON

Scroll the mouse to adjust zoom level. Click on node or arcs to display some information.

this part try using less

Max Node Value
Max Edge Value
zoom : 100%

JSON data from here http://codepen.io/superpikar/pen/LnHgD.js
          {
  "resourceId": 1400027639,
  "type": "ProcessModel",
  "nodes": {
        "Register": 1103,
        "Analyze Defect": 2206,
        "Repair (Complex)": 1447,
        "Test Repair": 3012,
        "Inform User": 1101,
        "Archive Repair": 999,
        "Repair (Simple)": 1568,
        "Restart Repair": 405
    },
    "mynodes": [
      {"name":"Register", "frequency": 1103},
      {"name":"Analyze Defect", "frequency": 2206},
      {"name":"Repair (Complex)", "frequency": 1447},
      {"name":"Test Repair", "frequency": 3012},
      {"name":"Inform User", "frequency": 1101},
      {"name":"Archive Repair", "frequency": 999},
      {"name":"Repair (Simple)", "frequency": 1568},
      {"name":"Restart Repair", "frequency": 405}
    ],
    "arcs": [
        {
            "from": "Register",
            "to": "Analyze Defect",
            "frequency": 1103,
            "dependency": 0
        },
        {
            "from": "Analyze Defect",
            "to": "Analyze Defect",
            "frequency": 1103,
            "dependency": 0
        },
        {
            "from": "Analyze Defect",
            "to": "Repair (Complex)",
            "frequency": 528,
            "dependency": 0
        },
        {
            "from": "Analyze Defect",
            "to": "Repair (Simple)",
            "frequency": 420,
            "dependency": 0
        },
        {
            "from": "Analyze Defect",
            "to": "Inform User",
            "frequency": 155,
            "dependency": 0
        },
        {
            "from": "Repair (Complex)",
            "to": "Repair (Complex)",
            "frequency": 414,
            "dependency": 0
        },
        {
            "from": "Repair (Complex)",
            "to": "Test Repair",
            "frequency": 719,
            "dependency": 0
        },
        {
            "from": "Repair (Complex)",
            "to": "Inform User",
            "frequency": 312,
            "dependency": 0
        },
        {
            "from": "Test Repair",
            "to": "Test Repair",
            "frequency": 1331,
            "dependency": 0
        },
        {
            "from": "Test Repair",
            "to": "Inform User",
            "frequency": 472,
            "dependency": 0
        },
        {
            "from": "Test Repair",
            "to": "Restart Repair",
            "frequency": 340,
            "dependency": 0
        },
        {
            "from": "Test Repair",
            "to": "Archive Repair",
            "frequency": 794,
            "dependency": 0
        },
        {
            "from": "Inform User",
            "to": "Archive Repair",
            "frequency": 205,
            "dependency": 0
        },
        {
            "from": "Inform User",
            "to": "Repair (Simple)",
            "frequency": 223,
            "dependency": 0
        },
        {
            "from": "Inform User",
            "to": "Repair (Complex)",
            "frequency": 401,
            "dependency": 0
        },
        {
            "from": "Inform User",
            "to": "Test Repair",
            "frequency": 180,
            "dependency": 0
        },
        {
            "from": "Inform User",
            "to": "Restart Repair",
            "frequency": 65,
            "dependency": 0
        },
        {
            "from": "Repair (Simple)",
            "to": "Repair (Simple)",
            "frequency": 625,
            "dependency": 0
        },
        {
            "from": "Repair (Simple)",
            "to": "Test Repair",
            "frequency": 782,
            "dependency": 0
        },
        {
            "from": "Repair (Simple)",
            "to": "Inform User",
            "frequency": 161,
            "dependency": 0
        },
        {
            "from": "Restart Repair",
            "to": "Repair (Simple)",
            "frequency": 300,
            "dependency": 0
        },
        {
            "from": "Restart Repair",
            "to": "Repair (Complex)",
            "frequency": 104,
            "dependency": 0
        },
        {
            "from": "Restart Repair",
            "to": "Inform User",
            "frequency": 1,
            "dependency": 0
        }
    ]
}


List of Nodes :
    List of Links :
